Quick Details

  • Condition: New
  • Type: Straightener & Cutter
  • Use: Bar
  • Place of Origin: Henan, China (Mainland)
  • Brand Name: YYTF
  • Model Number: SGT6-12
  • Voltage: 380V, 380V
  • Power(W): 7.5kw
  • Dimension(L*W*H): 1650*820*620mm
  • Weight: 750kg
  • Certification: ISO9001:2008
  • Warranty: 1 year
  • After-sales Service Provided: Engineers available to service machinery overseas
  • cutting length: 300mm to up
  • cutting error: ±5mm
  • whole weight: 750kg
  • Color: as you like
  • warranty: 1 year
  • HS code: 8462211000
  • Speed: 38m/min
  • steel bar straightening machine system: Hydralic
  • package: Iron frame and wooden case

Packaging & Delivery

Packaging Details SGT6-12 Hydraulic steel bar straightening and cutting machine is packed by wooden case and frame iron
Delivery Time Shipped in 10 days after payment

       SGT6-12 Hydraulic steel bar straightening and cutting machine



SGT6-12 Hydraulic steel bar straightening and cutting machine is a new-generation steel bar straightening machine developed by our company. The company is mainly applied in straightening, cold-rolled deformed bar of fixed-dimension cutting, hot rolling level III steel bar, cold-rolled round bar, and straightening hot-rolled round disk steel bar



   Specifications



SGT6-12 Hydraulic steel bar straightening and cutting machine
CapacitySteel Rod6mm-14mm
Rebar6mm-12mm
Cutting Length300mm to up
Cutting Error±0.5cm
Speed32m/min
Straighten&Traction Motor7.5kw
Voltage380v
Straightening Degree±2mm/m
Whole Weight750kg
Dimension2300*800*1100
Motor Optional220v/415v/440v
50HZ/60HZ

    Product Description



The machine is highly automatic, has high pulling speed, uses continuous working system and is equipped with automatic counting shut-down device. The security is high. The layout of the machine is different from other Models, so that it is easy to operate and repair. The straightening box uses long model, with 8 straightening wheels, which are easy to adjust curve. The machine is easy to operate and adjust, with high reliability and performance



The machine mainly consists of straightening part, material transmission part, cutting part, counting part, and electric control cabinet





  Quality Control And After-Sales Service



At Fengyida Machinery Manufacturing, we offer quality products that are subjected to rigorous quality testing measures to ensure that only the best products in terms of quality and design reaches the market. We believe that our clients deal with us because of the quality that we provide and are fully aware of our responsibilities of catering to the various needs and requirements in this regard.  We have adopted a system of total quality control to ensure that our products conform to strict industry standards and parameters. We use the quality imported parts and materials that are procured from reputed manufacturers. In addition, the different stages of production are closely monitored by our engineers to ensure complete satisfaction of the user of our products.



if quality problems cause the user to fail to use the machine, after repair the user still fails to use the machine. We promise to replace the machine with new one after the machine is sold within one month. The expenses generated hereof shall be borne by manufacturer (subject to effective bill). Components and parts (non-consumable parts) are under replacement and warranty within 3 months. If the whole machine suffers major quality problems such as engine body, box, and gear fracture, the warranty period is 6 months. If quick-wear parts of the machine listed in the below table have problems, the quick-wear parts are not in scope of three guarantees. (Remark: effective period is subject to date of invoice.)



   Certifications

ISO9001,CQC,SGS,BV







Culture Show

Processing Workshop

Our Team

Exhibitors Events



>>>More company details<<<

Always be imitated, Never be surpassed!

With 14 years experience, YongYiTongFeng insists in manufacturing small-sized construction machines. As a professional in this field, we pay more attention to quality than on variety. From a small workshop grow to be a professional manufacturer which gains RMB120,000,000.00 annual sales amount, our products cover Southeast Asia, South Asia, Middle East, South America, Africa, which brings us good reputation in global market. Being cautious and conscientious in small construction machines, with the spirit of spatiality and focus, we innovate and lead the steel processing market.
FAQ
----------------------YongYiTongFeng has ---------------------



1-Category Advantage

We provide full category of cutting machine, bending machine, straightening machine, stirrup machine,

bend-cutting combined machine.



2-Quality Advantage

Fast cost recovery. The High quality but Mid-range price, durable quality brings you continuous profits.



3-Technique Advantage

All machines are Fool-Type operation, new users could operate machine in few minutes.



4-Delivery Advantage

We set logistic center in large cities in China, assures you get machines at first time.



5-Service Advantage

We have after sales center in all around China, assures the quick reaction and solve problem at first time.

Overseas after sales service available, workers could be sent to install machine and train your workers.



Packaging & Shipping

Packaging & Shipping

We make sure the package is not damaged during long term shipping

Product packaging and export.
We adopt wooden and iron box to pack steel rod cutter machine, better guarantee the safety and quality of products, we adopt multiple port, multiple exit point.Such as Shanghai, Qingdao, guangdong and other regions.Product transportation will be faster and more convenient.



covered with plastic bag -- protect machine from water.

 plastic bag covered with stong waterproof bag -- double protect machine from

water and surface damage.

fix the machien into Iron shelf -- prevent from damage.

 carton cover onto the iron shelf -- protect the privacy of clients' goods.
