Quick Details

  • Condition: New
  • Place of Origin: Henan, China (Mainland)
  • Brand Name: yongyitongfeng
  • Model Number: GQ52
  • Voltage: 380V
  • Rated Power: 4KW-3phase
  • Dimension(L*W*H): 1400*530*850mm
  • Weight: 570KG
  • Certification: ISO-9001
  • Warranty: 1year
  • After-sales Service Provided: Overseas service center available
  • cutting capacity: steel rod≤50mm,IIrebar≤40mm
  • cutting frequency: 28times/min
  • motor power: 4KW-3phase
  • voltage: 380V
  • weight: 570KG
  • dimension: 1400*530*850mm
  • motor optional: 220V/415V/440V,50HZ/60HZ

Packaging & Delivery

Packaging Details Wooden cases or container
Delivery Time Shipped in 15 days after payment

PRODUCT DESCRIPTION


Product parameters and indicators



1. Reinforced enclosure, compact structure, movable wheels



2. Good lubricating properties. Adopt closed structure, use Gear Splash to lubricate, fill in 8-12kgs oil, the machine could work continuously for more than 3 month



3. Low power loss, seldom replacing of machine parts. The gear uses rolling bearing, low frication, could save 1/3 power comparing with similar rebar cutting machines



4. Quality core advantage

High hardness blade base and connection rod. Using high speed standard motor, high quality and steady performance, longer service life



All the gear shafts are produced by our own CNC processing center, high accuracy of size and excellent quality



All gears are extra thick and heavy, the whole machine is extra thick



Crank shaft is made by Cr40, high hardness and corrosion resistance, can work in heavy duty



Technical Parameters



Item

GQ52

Cutting Capacity



Steel Rod

≤50mm

II Rebar

≤40mm

Cutting Frequency

28times/min

Motor Power

4KW-3phase

Voltage

380V

Weight

570kg

Dimension(L×W×H)(mm)

1400×530×850

Motor Optional



220V/415V/440V

50HZ/60HZ





Machine show





Company Information





OUR TEAM

Products hall

reception hall

Accessories display

processing plant

Cutter assembly plant



>>>More company details<<<



Always be imitated, Never be surpassed!



With 14 years experience, YongYiTongFeng insists in manufacturing small-sized construction machines. As a professional in this field, we pay more attention to quality than on variety. From a small workshop grow to be a professional manufacturer which gains RMB120,000,000.00 annual sales amount, our products cover Southeast Asia, South Asia, Middle East, South America, Africa, which brings us good reputation in global market. Being cautious and conscientious in small construction machines, with the spirit of spatiality and focus, we innovate and lead the steel processing market.



Certifications

ISO9001,CQC,SGS,BV


Our advantages

At Fengyida Machinery Manufacturing, we offer quality products that are subjected to rigorous quality testing measures to ensure that only the best products in terms of quality and design reaches the market. We believe that our clients deal with us because of the quality that we provide and are fully aware of our responsibilities of catering to the various needs and requirements in this regard.

We have adopted a system of total quality control to ensure that our products conform to strict industry standards and parameters. We use the quality imported parts and materials that are procured from reputed manufacturers. In addition, the different stages of production are closely monitored by our engineers to ensure complete satisfaction of the user of our products.



 ~Timely Delivery



We take pride in our efficient production facilities, it enables us to fulfill different requirements of our clients within the stipulated time frame and as demanded by our clients.



if quality problems cause the user to fail to use the machine, after repair the user still fails to use the machine. We promise to replace the machine with new one after the machine is sold within one month. The expenses generated hereof shall be borne by manufacturer (subject to effective bill). Components and parts (non-consumable parts) are under replacement and warranty within 3 months. If the whole machine suffers major quality problems such as engine body, box, and gear fracture, the warranty period is 6 months. If quick-wear parts of the machine listed in the below table have problems, the quick-wear parts are not in scope of three guarantees. (Remark: effective period is subject to date of invoice.)



FAQ
----------------------YongYiTongFeng has ---------------------



1-Category Advantage

We provide full category of cutting machine, bending machine, straightening machine, stirrup machine,

bend-cutting combined machine.



2-Quality Advantage

Fast cost recovery. The High quality but Mid-range price, durable quality brings you continuous profits.



3-Technique Advantage

All machines are Fool-Type operation, new users could operate machine in few minutes.



4-Delivery Advantage

We set logistic center in large cities in China, assures you get machines at first time.



5-Service Advantage

We have after sales center in all around China, assures the quick reaction and solve problem at first time.

Overseas after sales service available, workers could be sent to install machine and train your workers.




-------------------------------------------------- Our Products ---------------------------------------------------
>>>Rebar Cutting Machine   >>>Rebar Tying Machine
>>>Rebar Stirrup Machine    >>>Related replacement parts
>>>Rebar Bending Machine    >>>Related Supporting Facilities
>>>Rebar Straightening and Cutting Machine >>>Rebar Coil Holder



Packaging & Shipping

We make sure the package is not damaged during long term shipping

Product packaging and export
We adopt wooden and iron box to pack steel rod cutter machine, better guarantee the safety and quality of products, we adopt multiple port, multiple exit point.Such as Shanghai, Qingdao, guangdong and other regions.Product transportation will be faster and more convenient.

covered with plastic bag -- protect machine from water.

 plastic bag covered with stong waterproof bag -- double protect machine from

water and surface damage.

fix the machien into Iron shelf -- prevent from damage.

 carton cover onto the iron shelf -- protect the privacy of clients' goods.
